超低温工作APD

cofiber612

Butterfly APD Receiver

ZGBxA1-701x-00

Description
The product integrates a high linearity InGaAs APD with TEC and thermistor, Low dark current, High linearity, High responsivity

Features:
Long wavelength operation
Package: 8pin & 14pin butterfly package
Built-in thermistor, and TEC
Low dark current
Excellent reliability compliance to GR-468-CORE
Compliance to RoHS standard

Applications
Optical fiber sensor system
Optical fiber communications system
Absolute Maximum Ratings

Parameter	Symbol	Min	Max	Unit	Condition
Operating Case Temperature	Tc	-40	85	°C	--
Storage Temperature	Tstg	-40	85	°C	--
Reverse Voltage	Vr	--	Vbr	V
Thermoelectric cooler voltage	VTEC		2.6	V
Forward current			5	mA
Reverse current			2	mA
Lead solder Temperature	--		260	°C	--
Lead Soldering Time	--		10	s	--

Optical/Electrical Characteristics (T=25℃，unless otherwise stated)

Parameter	Symbol	Min	Typ	Max	Unit	Test Conditions
Optical Wavelength	λ	1100	-	1650	nm
Breakdown Voltage	Vbr	40	48	53	V	Id=10uA；Tc=25℃~-20℃
Dark Current	Id	-		50	nA	Tc=25℃；VR=0.9Vbr
Responsivity	Re	0.85			A/W	λ = 1550nm；M=1；25°C Tc=25℃~-20℃
TEC Current	Itec	-	-	1500	mA	Tc=25℃； VR=0.9Vbr
Cutoff frequency	fc	2.0	3.5	-	GHz	Tc=25℃； VR=0.9Vbr
Capacitance	C		0.38	0.5	pF	f = 1MHz； Vr = 0.9 Vbr
Thermistor Resistance	RT	9.9	10	10.1	kΩ	@25℃
Thermistor B-Value		-	3950	-	K	25℃/85℃

Dimensions and Pin Description

Dimensions are in millimeters. All dimensions are ±0.1mm unless otherwise specified.
8pin butterfly package

Pin	Description
1	TE Cooler (+)
2	Thermistor
3	Thermistor
4	APD （P）
5	APD  (N)
6	NC
7	NC
8	TE Cooler (-)
